Description

• Mil-spec positioner used with (M22520/2-01) or similar tool
• Locates size 20 contacts
• Commonly used to locate pin and socket contacts installed in MIL-C-81659 connectors

Mil-spec M22520/2-08, is a bayonet positioner used with the mil-spec M22520/2-01, crimp tool frame on size 20 pin and socket contacts installed in MIL-C-24308, MIL-C-81659, MIL-STD-1549, ARINC 404, and ARINC 600 rectangular connectors.

Contact numbers:

M24308/10-1, M24308/11-1, M39029/11-145, M39029/12-149, M39029/63-368, M39029/64-369, M39029/67-374, M39029/67-375, M39029/67-376, M39029/67-377, M39029/67-378, M39029/68-379, M39029/68-380, M39029/68-381, M39029/68-382, M39029/68-383, M39029/93-538, M39029/94-542, 030-1892-002, 030-9081-003, 031-9134-004, 031-1047-002 ITT Cannon part number 995-0001-604

Manufacturer: Daniels Manufacturing Corporation
Condition: New Surplus
